序号
SER.NO | 零件名称
PART NAME | 编码
CODE | 数量
QTY |
1
2
3 | 蓄电池
后组合灯
倒车报警器 | BATTERY
REAR COMBINED LAMP
ALARM | W110024670
W370000320A
W370000010A | 2
2
1 |
4 5 6 | 倒车报警器盒子
垫 圈 6
垫 圈 6 | ALARM BOX
WASHER 6
WASHER 6 | Z5A02102900
B060410602
B060110602 | 1
12
6 |
7
8
9 | 螺栓M6×20
后车架线束
护线套 | BOLT M6×20
HARNESS ON REAR FRAME
COVER FOR HARNESS | B040910620
Z5B02100100
Z5A02102200 |  10
|
10
11
12 | 电源总开关(180A)
机油压力表进油管(3500)
机油压力表进油管接头 | MAIN POWER SWITCH
OIL PIPE FOR OIL PRESSURE METER
OILPIPEJOINT FOR OIL PRESSURE
METER | W110024070
Z420210040
Z320210190 | 4
1 |
13
14
15 | 先导阀线束
洗涤器线束
洗涤器 | HARNESS FOR PILOT VALVE
HARNESS FOR WASHER
WASHER | Z5A02100400
Z5A02100700
W370000040A |
|
16
17
18 | 后大灯
警示灯
电风扇 | REAR LAMP
BEACON
FAN | W370000330A
W110009990
W370000160B |
2
|
19
20
21 | 顶棚线束
收录机线束
收录机 | HARNESS ON CEILING
HARNESS FOR RADI0
RADI0 | Z3A02101600
Z5A02100500
W370000030A |
|
22
23
24 | 防雾灯
刮雨器
螺母M8 | ANTI-FOG LAMP
WIPER
NUT M8 | W370000420A
W370000340A
B050330807 | 8 |
25
26
27 | 垫 圈 8
垫 圈 8
螺栓M8×20 | WASHER 8
WASHER 8
BOLT M8X20 | B060410802
B060110802
B040910820 | 8
17
17 |
28
29
30 | 顶棚灯
螺钉M6×16
50F仪表盘 | CEILING LAMP
BOLT M6×16
CONSOLE ELECTRIC | W370000020A
B010210616
W370200000A | 2 |
|
31
32
33 | 扎带
前组合灯
前组合灯连接线(右) | CLIP
FRONT COMBINED LAMP
HARNESS FOR FRONT LAMP(RIGHT) | W370000370A
W370000310A
Z5A02102500 | 4 7 |
34
35
36 | 双音电喇叭
前车架线束
护线套 | HORN
HARNESS ON FRONT FRAME
COVER FOR HARNESS | W110022050
Z5A02100100
Z320210020 | 7 |
37
38
39 | 前组合灯连接线(左)
电瓶搭铁线
螺栓M10×20 | HARNESS FOR FRONT LAMP(LEFT)
BATTERY CABLE
BOLT M10×20 | Z5A02102400
Z520210320
B040911020 | 1
11 |
40
41
42 | 垫圈10
垫 圈 1 0
压力开关 | WASHER 10
WASHER 10
SWITCH OF PRESSURE | B060411002
B060111003
W110023910 | 10
11
1 |
43
44
45 | 刹车灯开关
行程开关撞击板
行程开关固定座 | PRESSURE SWITCH FOR BRAKE INDICATE
PLANK FOR REVERSING LIGHT
FIXATION FOR REVERSING LIGHT | W370400000
Z520210310
Z520210300 | 1 |
46
47
48 | 倒车灯开关
扎带
温度传感器 | REAR LAMP SWITCH
CLIP
SENSING PLUG FOR TEMPERATURE | W110022970
W11001370
W370000070A | 4
2 |
49
50
51 | 电瓶搭铁线
护套
起动机电瓶线 | BATTERY CABLE
COVER
BATTERY CABLE | Z520210330
W370000070
Z5A02102000 |
|
52
53
54 | 电瓶线
电瓶连接线
正极护套 | BATTERY CABLE
BATTERY CABLE
COVER FOR POSITIVE TERMINAL | Z3A02101800
Z520210340
W110024960 | 2
2 |
55
56
57 | 断路开关
负极护套
电瓶卡子 | DISCONNECTED SWITCH
COVER FOR NEGATIVE TERMINAL
BATTERY TERMINAL CLAMP | W110025560
W110024970
W110024810 | 1 3 2 |
